Cold wire Feeder CW 06

CW 06 Robot is extremely handy tool that can greatly facilitate the work of welders in stationary welding of growth of labor productivity, reduce the cost of welding material and increases the quality of production. The robotic operation mode allows perfect work results at a fraction of the investment in traditional solutions use cold wire.

• CW 06 Robot is robotic Cold Wire Feeder with wide application. It is fully digital device that can work as auxiliary equipment for TIG AC and DC TIG, may operate in the plasma beam welding (Plasma Weld) or with laser applications with feeding the wire in the range of 0,6 - 1,6mm.
• CW 06 Robot is designed for automatic mode where is controlled by external device. CW06 is equipped with control input for connection of exterenal device into 12VDC system via which is possible to control START/STOP funcionality for switching of working cycle and to control speed of cold wire feeding into the weld in steps. It is therefore possible to connect CW06 to higher-level system, including welding robot and to control above mentioned functions by analog command of other host system. However, the technological functions and parameters of feeding have to be always set directly in CW 06 feeder control system.
• CW 06 Robot is made to be extremely durable steel self-supporting structure welded from sheet steel. Under the steel door is four roller wire feeder from the other side is mounted control electronics. On the front is the connection of cables of wire into the handle. Designed hole at the top of the hidden control panel that displays the parameter setting and its location prevents accidental damage to electronics. In the back of the feeder is systems connections. Plastic cover coil wire type K 300, with a maximum load of 20 kg. The entire device stand on four-wheeled chassis with front swivel wheels. Highly sophisticated ergonomics use practical handle to frame built into the device so that it can be in a balanced position, easy to carry.
• System of feeding is designed as unique construction system that is the result of HST CREATIVE research and development department activities and is patented. The device consists of four – roller feeder driven by especially designed digitally controlled driver. Construction of the driver eliminates ordinary problems with dynamics of feeding and may be operated even with high values of feeding – backwards and forwards by oscillation in 100% linearity of feeding up to limit frequency of feeding.
• CW 06 Robot is controlled by special control system which provides all of the sophisticated functions through the system of display and multifunction button. Feeder is equipped with a controlled valve that can open and close the inlet forming gas. Another option is connection of the torch with fixed feeding of wire into the weld.

Benefits of product

√  Unique characteristics of the device enable any type of welding including the feeding of aluminium products without defects of the wire.

√  Feeding of the wire is even by welding with high oscillatory values of feeding forwards and backwards 100% linear up to limit frequency of feeding.

√  Precise feeding with displaying the parameter of amount of the wire brought into the weld in mm3/min fully suitable even for laser welding.

√  Simple but functional controlling through the system of one display and one multifunctional botton.

√  High - quality options taking the different methods of welding in consideration.
