Horizontal welding automat HMS 1750.02

Complete machine base ready for precise configuration

(( 1 )) Selection of tailstock type as driven or non-driven variant
(( 2 )) Selection of the torch welding arm and the functionality of torch holding elements
(( 3 )) Selection of technological accessories and improvements
(( 4 )) Selection of welding source and other accessories and complements

Complete group of construction, linear guides and all energy pathways

(( √ )) Item is necessary for the intended function of the machine, NO ALTERNATIVE
(( Combination )) Selection of this item extends the working length of the machine. The MAXIMUM is 7
(( Options )) On request is possible to change the stroke of the tailstock pressure cylinder and its force
(( Condition )) Construction change which affects the design of the machine in an unchanging way

Structural accessory to increase stability of portal for the length between flanges over 5500mm

(( √ )) Additional supports to increase stability and strength of welding heads portal, NO ALTERNATIVE
(( Combination )) None
(( Options )) None
(( Condition )) Assembled and mounted directly at the production

Structural accessory serving as shelf for possible welding source - LEFT side as seen from the front

(( √ )) Welding source shelf LEFT, HAS AN ALTERNATIVE (1.4)
(( Combination )) With the second RIGHT shelf in case of using of two welding sources
(( Options )) Custom made dimension adjustment for specific welding source
(( Condition )) Assembled and mounted directly at the production

Structural accessory serving as shelf for possible welding source - RIGHT side as seen from the front

(( √ )) Welding source shelf RIGHT, HAS AN ALTERNATIVE (1.3)
(( Combination )) With the second LEFT shelf in case of using of two welding sources
(( Options )) Custom made dimension adjustment for specific welding source
(( Condition )) Assembled and mounted directly at the production

Complete tailstock without tilting of spindle and freely rotating spindle (flange 315mm, hole 108mm)

(( √ )) Item is necessary for intended function of the machine, HAS AN ALTERNATIVE (2.2)
(( Combination )) Selection of this item precludes the selecting of item (2.2), can be equipped with spindle drive
(( Options )) On request is possible to change the stroke of the tailstock pressure cylinder and its force
(( Condition )) Assembled and mounted directly at the production

Complete tailstock with controlled tilting of spindle and freely rotating spindle (flange 315mm, hole 108mm)

(( √ )) Item is necessary for intended function of the machine, HAS AN ALTERNATIVE (2.1)
(( Combination )) Selection of this item precludes the selecting of item (2.1), can be equipped with spindle drive
(( Options )) On request is possible to change the stroke of the tailstock pressure cylinder and its force
(( Condition )) Assembled and mounted directly at the production

Synchronized drive of the tailstock for Mk.I version which can be use for both variants of the tailstock

(( √ )) Item is optional to increase of the torque on the shaft of rotary axis, NO ALTERNATIVE
(( Combination )) This item can be use with both variants of tailstock, i.e items (2.1), or (2.2)
(( Options )) None
(( Condition )) Assembled and mounted directly at the production

Synchronized drive of the tailstock for Mk.II version which can be use for both variants of the tailstock

(( √ )) Item is optional to increase of the torque on the shaft of rotary axis, NO ALTERNATIVE
(( Combination )) This item can be use with both variants of tailstock, i.e items (2.1), or (2.2)
(( Options )) None
(( Condition )) Assembled and mounted directly at the production

Synchronized drive of the tailstock for HighPower version which can be use for both variants of the tailstock

(( √ )) Item is optional to increase of the torque on the shaft of rotary axis, NO ALTERNATIVE
(( Combination )) This item can be use with both variants of tailstock, i.e items (2.1), or (2.2)
(( Options )) None
(( Condition )) Assembled and mounted directly at the production

Additional welding arm with own support and controlled motoric stroke of torch in axis Z

(( √ )) This item is optional if two torches are necessary, NO ALTERNATIVE
(( Combination )) This item have to be further fitted with items (5.1), (5.2), or (5.3)
(( Options )) The maximum number of additional torch heads on one machine is one
(( Condition )) Assembled and mounted directly at the production

Second independent controlled X axis for longitudinal movement of additional torch head (4.1)

(( √ )) This item is optional, NO ALTERNATIVE
(( Combination )) Must be combined with item (4.1) and CanOpen digital controling (13.4)
(( Options )) None
(( Condition )) Assembled and mounted directly at the production

Cross head with precise adjustment of +/-15mm in axes X and Z and rotation of torch holder with fixation per each 30°

(( √ )) Item is necessary for intended function of the machine, HAS AN ALTERNATIVE
(( Combination )) This item have to be further fitted with item (ARM 2 TILT TORCH HOLDER)
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tools

Cross head with precise adjustment of +/-15mm in axes X and Z, rotation of torch holder with fixation per each 30° and side turning possibility +/- 90°

(( √ )) Item is necessary for intended function of the machine, HAS AN ALTERNATIVE
(( Combination )) This item have to be further fitted with item (ARM 2 TILT TORCH HOLDER)
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tools

Holder for MIG or TIG torch with tilting function at five fixed angles per each 15°

(( √ )) Item is necessary for intended function of the machine, NO ALTERNATIVE
(( Combination )) ARM 2 SLIDEMICRO is mounted on this part in the case of cold wire feeder is installed
(( Options )) Select a diameter of the torch, standard is 34mm. It have to always be a straight torch
(( Condition )) Can be installed in a simple operation without use of special tools

Holder for TIG torch with electromagnetic sensor for height tracking of the torch above the weldment

(( √ )) Can be used only in combination with numeric stroke of torch in Z axis, HAS AN ALTERNATIVE
(( Combination )) ARM 2 SLIDEMICRO is mounted on this part in the case of cold wire feeder is installed
(( Options )) Select a diameter of the torch, standard is 34mm. It have to always be a straight torch
(( Condition )) Assembled and mounted directly at the production

Holder for TIG torch with electromagnetic sensor for height tracking of the torch above the weldment

(( √ )) Can be used only in combination with numeric stroke of torch in Z axis, HAS AN ALTERNATIVE
(( Combination )) ARM 2 SLIDEMICRO is mounted on this part in the case of cold wire feeder is installed
(( Options )) Select a diameter of the torch, standard is 34mm. It have to always be a straight torch
(( Condition )) Assembled and mounted directly at the production

Feeder of cold wire 1,2 and 1,6 mm for TIG welding or PLASMA WELD

(( √ )) This item extends the functionality of the machine with effect to welding technology, NO ALTERNATIVE
(( Combination )) ARM 2 SLIDEMICRO have to be selected for proper function
(( Options )) None
(( Condition )) Assembled and mounted directly at the production

Cold wire feeding end element with the possibility of precise adjustment +/-5mm with cooled girder

(( √ )) Precisely made set feeds cold wire directly into the weld, NO ALTERNATIVE
(( Combination )) Mounted on the ARM 2 TILT TORCH HOLDER
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tool

SET for solenoid control of forming gas - one way

(( √ )) Auxiliary element that improves the operation by switching the forming gas flow, NO ALTERNATIVE
(( Combination )) None
(( Options )) None
(( Condition )) Assembled and mounted directly at the production

Separate float flow meter with precise needle valve. Mounting on the surface through hole

(( √ )) Auxiliary equipment that improves the machine funcionality, bringing gas savings, NO ALTERNATIVE
(( Combination )) Mounted on the machine or can be mounted on a free-standing carrier, height 950mm
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tools

Liquid cooling system for up to four welding torches integrated into the main portal support

(( √ )) Optional, can be used if welding source is not equipped with own cooling system, NO ALTERNATIVE
(( Combination )) None
(( Options )) None
(( Condition )) Assembled and mounted directly at the production

Fume exhausting SET integrating suction nozzle, piping and terminal element for connecting of exhausting

(( √ )) Auxiliary element for connecting of external exhausting system, NO ALTERNATIVE
(( Combination )) None
(( Options )) None
(( Condition )) Assembled and mounted directly at the production

Digital remote control with backlit display with the possibility of configuration of button functionality

(( √ )) Improves machine usability and facilitates direct welding control, NO ALTERNATIVE
(( Combination )) It is advisable to add a Holder for Mighty Controller
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tools

Holder for remote control Mighty Controller freely mountable on any surface or the machine

(( √ )) Reduces the risk of damage to the Mighty Controller, NO ALTERNATIVE
(( Combination )) Used in conjunction with Mighty Controller
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tool

Set of internal electronics and installation elements for connecting of another source to the machine

(( √ )) Extends functionality of machine with the parallel welding with additional source, NO ALTERNATIVE
(( Combination )) Can be used with any kind of welding source on the analog START/STOP principle
(( Options )) Up to four simultaneous sources can be connected on request
(( Condition )) Assembled and mounted directly at the production

Set of internal electronics and installation elements for digital connection of welding source

(( √ )) Allows full control of welding source, including program switching, NO ALTERNATIVE
(( Combination )) Can be used only with HST CREATIVE and CEBORA, limitedly LORCH (on request)
(( Options )) Two independent welding sources can be connected
(( Condition )) Assembled and mounted directly at the production

Software extending functions of the machine with londitudinal welding and pendel function in rotary mode

(( √ )) Item is optional to increase the software functionality of machine, NO ALTERNATIVE
(( Combination )) Can be used only with drive of torch head longitudinal movement - controlled axis X (4.1)
(( Options )) None
(( Condition )) Installed directly at the production

Software extending functions of the machine with layered screw

(( √ )) Item is optional to increase the software functionality of machine, NO ALTERNATIVE
(( Combination )) Can be used only with drive of torch head longitudinal movement - controlled axis X (4.1)
(( Options )) None
(( Condition )) Installed directly at the production

Special set of weldment preheating containing complete technology, construction elements and SW equipment

(( √ )) Item is intended for preheating the material before welding on set temperature, NO ALTERNATIVE
(( Combination )) None
(( Options )) Preheating torch can be selected for any gaseous fuel
(( Condition )) Construction change which affects the design of the machine in an unchanging way

Three-jaw universal chuck with gears adjusted for welding, hole 78mm, weight 22.2kg

(( √ )) Chuck can be mounted on spindle flanges without transition elements, HAS AN ALTERNATIVE
(( Combination )) The chuck can be fitted with extended segments (custom made solution)
(( Options )) Other chucks can be choosed, but these have to be mounted using transition elements
(( Condition )) Can be installed in a simple operation without use of special tools

Three-jaw universal chuck with gears adjusted for welding, hole 108mm, weight 42.5kg

(( √ )) Chuck can be mounted on spindle flanges without transition elements, HAS AN ALTERNATIVE
(( Combination )) The chuck can be fitted with extended segments (custom made solution)
(( Options )) Other chucks can be choosed, but these have to be mounted using transition elements
(( Condition )) Can be installed in a simple operation without use of special tools

Three-jaw universal chuck with gears adjusted for welding, hole 144mm, weight 76,1kg

(( √ )) Chuck can be mounted on spindle flanges without transition elements, HAS AN ALTERNATIVE
(( Combination )) The chuck can be fitted with extended segments (custom made solution)
(( Options )) Other chucks can be choosed, but these have to be mounted using transition elements
(( Condition )) Can be installed in a simple operation without use of special tools

Vertically and transversely adjustable pipe support with pneumatic pressure and five pulleys

(( √ )) Mounted on the linear guide of the machine by means of rolling nests, NO ALTERNATIVE
(( Combination )) None
(( Options )) Functional ranges can be customized on request
(( Condition )) Can be installed in a simple operation without use of special tool

Vertically and transversely adjustable pipe support with independent arms for optimal tangential supporting

(( √ )) Mounted on the linear guide by means of rolling nests, HAS AN ALTERNATIVE (PARALLEL SUPPORT)
(( Combination )) None
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tool

Vertically and transversely adjustable pipe support with arms clamped by a double-sided moving screw

(( √ )) Mounted on the linear guide by means of rolling nests, HAS AN ALTERNATIVE (SPATIAL SUPPORT)
(( Combination )) None
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tool
