Universal welding automat EWR 1050.108
MACHINE VARIANTS
Necesary choice
The green color indicates an element or the part that have to be installed to the machine in one of the offered variants already during its production and the machine cannot be forward into the operation without it, or order it.
Construction surcharge
Yellow coloring means an element or the part which have to be installed into the machine in some of the offered variants already during its production. In principle it is a device extending functionality.
Free equipment
The gray coloration indicates an element or the part which is possible to fit the machine at any time later. Assembly is possible by the end user. In principle it is an equipment which expands functionality.
Purpose of machine is to work across entire breadth of production across the range of industry fields. The machine excels in its versatility and its well-thought-out design which allows any rotary welding and conditional welding of longitudinal seams (not welding on a copper pad - for this purposes are designed our automats from AWL line). It is possible to weld very small parts and large weldments on the machine as well as welding of armature and other pipe or rod materials thanks to the hollow spindle. Machine can be used also for layered screw welding of horizontally clamped cylinder. RCS 06 control system brings to the operator the perfect functionality for full automation of the rotary welding process, or screw layered welding.
-
EWR HUNTER 1050.108 is universal rotary welding automat with maximum turning diameter of 650 mm and maximum static loading of 270 kg. Distance between the spindle flanges is 1050 mm. There is no limit for using of welding methods.
- Automat can be supplied in three production versions - Mk.I, Mk.II, or Mk.III. The spindle speed range for Mk.I version is set higher for rather lighter products of smaller diameter for rotation at higher speed however less torque is available. The Mk.II version has universal torque and spindle speed range for use with the standard sizes of welded products. The spindle speed range of Mk.III version is set lower. However higher torque is available for use with bulkier products of larger diameters with weight closer to the maximum allowed loading of automat. Therefore the choice of version should depend on the expected use.
-
Mechanical sandwich construction carries massive central block into which the main hollow spindle with hole of 108mm is integrated. Central block carries main beam of linear pathways carrying tailstock and arm of welding torch. Set of the central block and the main beam can be tilted even as controlled axis T with own drive with elevation in the range of 0 - 90 ° with advantage for welding in positions.
-
Tailstock can be equipped with own drive. Both drives are synchronized and designed as backlash-free. Stepper motor spins precise planetary gearbox that propel belt and gears wheels with transverse teeth. Main spindle and the tailstock have standardized flanges of different kinds for mounting the universal chuck 315mm with hole of 108mm for main spindle and the universlal chuck 125mm with hole of 28mm for the tailstock.
-
The whole central beam can be tilted in the range of 0 - 90°. Tilting can be done manually with handle through snail gearbox or by own drive as controlled axis T. Therefore it is possible to accurately set any of the positions in order to optimize welding process.
-
Tailstock pressure is designed as linear with pneumatic cylinder 63mm with a standard stroke of 50mm (stroke can be increased on request).
-
Torch head can be eqquiped with servo drive with numerically controlled X axis for movement in longitudinal direction. The welding head is designed as version for one welding technology when the machine can be equipped with two welding technologies of the same type simultaneously on two torch heads (in the case of two different welding technologies or two different type of welding sources consultation is required). The welding arm can have simple pneumatic stroke and three degrees of releasing or can be designed as numerically controlled Z axis with welding arm mechanically adjustable in three degrees of releasing. At the end of the arm there is precise support of the torch position with backlash-free adjustment in two axes +/- 15 mm and the possibility of rotation by 90 ° with position locking. Torch holder can be MIG, TIG or PLASMA WELD (others are on request).
-
Welding arm can be equipped with special system for torch monitoring by electromagnetic sensor. This system is designed for automatic torch height tracking above the welded material (product) during welding process done by the stroke of the welding arm via axis Z based on the datas form the sensor. For this functionality is necessary to equipped the machine with motor-driven stroke of torch head - controlled axis Z.
-
Machine can be equipped with cold wire feeder HST CREATIVE CW 03. The cold wire feeder is fully controlled by the RCS06 control system and brings to the operator the maximum possibilities of setting of the feeding parameters including the reversation of the feeding of the wire.
-
Significant simplification for the operator can be the equipment of the machine with a special digital Remote Control Mighty Controller which increases the flexibility and variability of the basic machine.
-
Machine is controlled by the excellent control system RCS 06 which provides all conceivable functions for circumferential welding, including accelerations and decelerations of rotary movement, control of the welding source with separate programming and advanced functions of regulation of welding power. The possibility of saving programs and creating program compilations underline the sophistication of the control system.
Using possibilities in a terms of weld type and technology
√ Circumferential welding with one or two identical torches. Multiple torches = adjustment.
√ Longitudinal welding and oscilation with controlled X axis.
√ Tilting of central beam 0 - 90°, performing of fillet and position welds.
√ Control of the welding source by digital protocol Opencan or analog.
√ Feeding of the cold welding wire into the weld (TIG, PLASMA).
√ Protection of the root of the weld by controlled valve (max. 2 ways).
√ Layered screw welding with the possibility of controlled preheating.
X Layered spiral welding with interpolation of rotation and torch displacement.
X Equipping with more different welding technologies (requires consultation).
X Radial oscillation.
Main benefits
√ RCS 06 control system specially designed for welding tasks with high functional equipment.
√ Backlash-free drives with concept in the composition of Stepper motor > Planetary gearbox > Toothed gear wheels transmission > Spindle.
√ Through-hole spindles with standardized flanges for connecting a standard universal chucks.
√ Tailstock pressure in the longitudinal axis by pneumatic cylinder, movement along the precise linear guides.
√ Sophisticated torch arm with many degrees of releasing achieving high variability for internal and external welding.
√ Durable design with protection of sensitive parts, transmission of welding current by professional milled CuCrZr wiper.
|
WORKING PARAMETERS |
VALUE |
|
Maximal static loading |
270,0 Kg |
|
Torque on the main spindle shaft (Mk.I / Mk.II / Mk.III) |
181,2 / 362,0 / 604,0 Nm |
|
Static angle clearance of the main spindle (loading not considered) |
- |
|
Torque on the tailstock shaft (synchronized drive with the main spindle)(Mk.I / Mk.II / Mk.III) * |
181,2 / 362,0 / 604,0 Nm |
|
Stati angle clearance of the tailstock spindle (loading not considered) |
- |
|
Torque on the elevation shaft (T axis) * |
7862,4 Nm |
|
Speed range (Mk.I / Mk.II / Mk.III) |
0 - 11,1 / 0 - 5,6 / 0 - 3,3 rpm |
|
Pressure of the tailstock towards the main spindle |
- |
|
Duty cycle ** |
24/7 |
| DIMENSIONS |
VALUE |
| Maximal turning diameter | 650,0 mm |
| Distance between the main spindle and tailstock spindle flanges * | 1050,0 mm |
| Hole through the main spindle | 108,0 mm |
| Diameter of the main spindle flange - recommended diameter of universal chuck | 315,0 mm |
| Recommended working plate | 650,0 x 14,0 mm |
| Hole through the spindle of the tailstock | 28,0 mm |
| Diameter of the tailstock spindle flange - recommended diameter of universal chuck | 125,0 mm |
| Tailstock working cylinder stroke (standard delivery, adjustment on request) | 50,0 mm |
| MOTION AXES | VALUE |
| Rotation of the main spindle | Controlled axis |
| Rotation of the tailstock spindle (synchronized with main spindle) * | Controlled axis |
| Elevation of the central beam (T axis) * | 0 - 90°, controlled or manual axis |
| Longitudinal movement of the welding arm (X axis) * | Full function, controlled axis |
| Stroke of the welding arm (Z axis) * | +/- 150,0 mm, or pneumatically in arc |
| Tilting of the welding arm to sides | +/- 45°, manual axis |
| Adjustment of thewelding arm basic position (3 joints) | Full function, manual axis |
| Precise adjustment of the torch position | +/- 15,0 mm, manual axis |
| Precise adjustment of the wire feeding * | +/- 5,0 mm, manual axis |
| TECHNOLOGY OF WELDING AND CONTROLLING | VALUE |
| Suitable methods of welding | MIG/MAG, TIG, Plasma Weld, Laser |
| Electric current for DC transfered by spindle | 450A |
| Electric current for AC transfered by spindle | 350A |
| Connection of the welding source through START/STOP system | Yes |
| Connection of the welding source through the system of UP/DOWN logic | Yes |
| Automatic torch height monitoring by axis Z - electro mechanic sensor (MIG/MAG, TIG) * | Yes |
| Connection of the welding source via digital interface CanOpen (CEBORA, LORCH) * | Yes |
| Programmable feeding of the wire (0,6 / 0,8 / 1,0 / 1,2 / 1,6 mm)(Fe / CrNi / CrMo / Flux / Al / Cu) * | Yes |
| Remote control * | Yes |
| POWER SUPPLY | VALUE |
| Power supply | 3x400V/N/PE/50Hz |
| Pressure air (dry, clean) | 0,5 - 0,7 MPa |
| Protective gases for welding | 1 independant way |
| Protective gases for root protection * | 2 independant ways |
| Design | Stand desing, necessary to anchor |
| Level of IP | IP 51 C |
| Input power *** | - |
| DIMENSIONS | VALUE |
| Height | 1450 mm |
| Width | 1700 mm |
| Length | 2674 mm |
| Net weight *** | 450 Kg |
* Optional item, or more versions are available which differs according to function. Mentioned parameters are valid for maximal options.
** 8/5 = lower loading in one duty period /// 16/6 = industrial loading /// 24/7 = non - stop loading
*** Parameters can not be provided with 100% correctness. Configuration of the machine must be taken into consideration. Mentioned parameters are valid for reaching maximal effective value.
...Subject to change the technical parameters without notice.
...The information given here describes entire RCS 06 control system with all possibilities which however may not be available for every machine depending on technological possibilities of specific machine. It also depends on selected machine configuration. Therefore is always necessary get acquainted with the specific machine at first whether its technological possibilities, even with regard to the configuration you have chosen, support all functions described below, or not. Informations given in here are the overview about possibilities of control system, not the machine and do not give explanation of individual components because of difficult comprehensibility of more complicated functions and equipment. For more details, please, contact the technical department or sales of HST CREATIVE.
Control system RCS 06
WORKING DATA
Basic choices
- Settings of the basic informations about the production (Rotary welding, linear welding, Layered screw or spiral welding)
- Settings of information about diameter of the product (Middle diameter of weld in mm)
- Assigning of the specific welding source to the specific welding head.
Axis...Rotation
- The direction of the rotation - Left or Right
- The delay of the rotation before the welding (time after the confirmation of the stable arc is sent from the welding source)
- First acceleration (settings of angle and value)
- Angle of rotation (maximal 720°, exactness 0,1°)
- Acceleration during the turning (settings of angle and value)
- Deceleration at the end of the turning for creating of the precise closing sequence and defect-free connection of beginning and end of the weld in a rotary welding (settings of angle and value)
- Spot welding (function enables to put regularly placed welded points along the circumference of welded product)
- Return to start point 0 (exact return to the start point - settings as shorter way or the whole way back)
Axis...Motoric
- In rotary mode of welding - the setting of the longitudinal welding position on the X Axis and its acting during the working cycle
- In longitudinal mode of welding - the setting of the welding position, the delay of activity after the welding process has started, the final time of welding, finishing of the sequence, the acting during the working cycle and radial position of the weld on the rotary axis
- The angle of tailstock's spindle 0- 90° (some of the machines). The fluent movement using the exact drive of tailstock's tilt or the logic of this function in case that the machine is equipped by the tailstock with pneumatically controlled stroke.
Axis...Of the torch
- The height of welding set by Z axis or the logic of controlling the pneumatical stroke of the torch.
- The position of welding set by another controlled axises of the arm of the torch (Z and K axis or the five - axis jointed arm).
Pendel
- The delay of the pendel after the confirmation of the stable arc is sent by the welding source.
- Frequency of the oscillatory movement (Hz).
- Right/Left divergence (in mm, separately for each side, exactness 0,1mm).
- Right/Left delay, delay in the middle (sets the linearity of pendeling, setting in sec.).
- The choice of programmed pendeling to some of the controlled axises.
The wire feeder (feeder CW 03, or CW 09 is needed)
- The delay of starting the wire feeding after the sign of the stable arc is sent by the welding machine (sec).
- Frequency of feeding. The frequency of changes in the speed of feeding of the wire (Hz).
- The Top (A) and Bottom speed (B) of feeding. Individual speeds (AB) of feeding are set separately (0 - 10m/min).
- The crumb. Setting of ratio between Top and Bottom speed of feeding (set in %).
- Oscillating wire reversation. It changes the direction of the wire feeding in the sense of setting of the bottom feeding speed (the wire burns out in batches with all of the benefits of this wire feed procedure
- Wire is pull in at the end of welding to prevent residual oxidation of the wire.
Controlling the source
- Control of the welding source depending on the selected system. Full MASTER digital control via HST CREATIVE OpenCan interface. Or simple analog controling via the REL analog element.
- Set of welding source switching ON angle (0 - 720°) and welding source switching OFF angle (max. 720°).
Forming gas
- Pre-blowing and after-blowing of forming gas into the torch for welding source number 1 and for welding source number 2.
- Pre-blowing and after-blowing of forming gas.
Another device
- Setting of digital remote control "Mighty controller"
- Control of the HST CREATIVE NICK 03 camera system (position setting and shooting parameters).
- High-precision control of welding position above the welded surface sensing by electromagnetic touch sensor.
- Welding data scanning and welding quality evaluation system.
- Connection of other external systems.
PROGRAMS - MEMORY BOXES
- The machine can memorize the own settings including the whole working cycle. There is a possibility to name, edit, copy, shift (199 free positions)
PROGRAMS - COMPILATION
- Programs safed in Memory boxes can be arbitrarily combinated into the functional lines and can create even the difficult working cycle. For example it is possible to weld like that (fully automated cycle with visual checking always with program changing - BREAK function):
Program 1 - The root layer of the weld done by TIG method without pendelling of the torch, speed range 45cm/min, without additional wire, power supply 72A.
Program 2 - The layer number two done by TIG method with pendelling of the torch and using the cold wire feeder, speed range 65 cm/min, power supply 160A.
Program 3 - The layer number three done by MAG PULSE method with pendelling of the torch, speed range 72cm/min, power supply 235 A.
QUICK OPTIONS
- Choice between automatic and manual mode at the touch of one button.
- "No Weld" function is available used to test the settings without welding.
- "Triangulation" button. A special button that is used to save the current positions of all controlled machine axes based on visual inspection by the operator. The machine records the visual input as the detected coordinates of the controlled axes.
DIRECT FUNCTIONS
- Forming gas test button (opens all of the gas valves when pressed).
- Welding torch manual tilt button.
- Button for manual closing of the pneumatic elements (for example tailstock pressing).
WELDED PARTS
- The machine is a universal and sophisticated production unit with the ability to weld any of the industrial production within the dimensional and weight limits of the machine. It is possible to perform rotary circumferential welds, fillet welds in the PA / PB position thanks to the tilting tailstock (only in the case of some of the machines) and it is also possible to perform full-fledged longitudinal welds (only the machines with controlled X axis).
- Typical is the production of pressure and non-pressure tanks from all materials with all of the methods of arc welding with the exception of the SAW method. Thanks to the high overall accuracy the machine enables welding of machine parts, flanges, shafts, heat exchangers, tube sheets.
- The machine is able to work in a layered screw welding mode (only the some machines) on the surface of the cylinder and also on the surface of the plate by the spiral layered welding tilted to the 90° (only the machines equipped with the tilting tailstock). Spiral layered welding has interpolated rotation and torch movement - change spindle rotation speed depending on the current diameter. The special software also provides the possibility of welding individual layers of layered welds (it uses a controlled Z axis of the torch stroke). It is also possible to equip the machine with the controlled preheating system of the welded part with digital surface temperature measurement.
TIPS FOR BETTER USE
- An excellent addition is the sophisticated Mighty Controler remote control. It is a freely programmable device by which is possible to control all of the necessary machine functions directly during the welding.
- The control system of the machine is well developed, it provides on-line information about the current rotation speed and the current progress speed. Operating is done using the standard multi-layer MENU.
- Software compilations provide perfect possibilities for fully automated production composite of many different welds.
- Double Torch versions does not restrict the users in the production of technologically complex products and aplications. One method can be used for welding of the root of the weld, another one can be used for the covering layers.
- The tilting tailstock significantly expands the usability of the machine by position welding at angles of 0 - 90°.
- Digital cold wire feeders provide precise welding results in the widest range of applications.
Basic configuration of the machine
C, D, E
Complete machine base ready for precise configuration
(( 1 )) Selection of tailstock type as driven or non-driven variant
(( 2 )) Selection of the torch welding arm and the functionality of torch holding elements
(( 3 )) Selection of technological accessories and improvements
(( 4 )) Selection of welding source and other accessories and complements
Basic equipment for automatization
1.1
Complete tailstock without drive with freely rotating spindle (flange 125mm, hole 28mm)
(( √ )) Item is necessary for intended function of the machine, HAS AN ALTERNATIVE (Motorized tailstock)
(( Combination )) Selection of this item precludes the selecting of item (Motorized tailstock)
(( Options )) On request is possible to change the stroke of the tailstock pressure cylinder and its force
(( Condition )) Assembled and mounted directly at the production
1.2
Complete tailstock with synchronized drive with main spindle (flange 125mm, hole 28mm)
(( √ )) Item is necessary for intended function of machine, HAS AN ALTERNATIVE (Non - motorized tailstock)
(( Combination )) Selection of this item precludes the selecting of item (Non - motorized tailstock)
(( Options )) On request is possible to change the stroke of the tailstock pressure cylinder and its force
(( Condition )) Assembled and mounted directly at the production
1.3
Complete tailstock with synchronized drive with main spindle (flange 125mm, hole 28mm)
(( √ )) Item is necessary for intended function of machine, HAS AN ALTERNATIVE (Non - motorized tailstock)
(( Combination )) Selection of this item precludes the selecting of item (Non - motorized tailstock)
(( Options )) On request is possible to change the stroke of the tailstock pressure cylinder and its force
(( Condition )) Assembled and mounted directly at the production
1.4
Complete tailstock with synchronized drive with main spindle (flange 125mm, hole 28mm)
(( √ )) Item is necessary for intended function of machine, HAS AN ALTERNATIVE (Non - motorized tailstock)
(( Combination )) Selection of this item precludes the selecting of item (Non - motorized tailstock)
(( Options )) On request is possible to change the stroke of the tailstock pressure cylinder and its force
(( Condition )) Assembled and mounted directly at the production
2
Specifies the length in millimeters of the stroke of the pneumatic cylinder
(( √ )) Standard stroke is 50mm, more then standard stroke decreases working length
(( Combination )) None
(( Options )) None
(( Condition )) Assembled and mounted directly at the production
3.1
Structural accessory serving as fixation of central beam in specified position, without elevation
(( √ )) This item fixing central beam when elevation is not required, HAS AN ALTERNATIVE (3.2, 3.3)
(( Combination )) Selection of this item precludes the selecting of item (3.2, 3.3)
(( Option )) Specific angle in the range of 0 - 90 ° can be choose for fixing the central beam
(( Condition )) Assembled and mounted directly at the production
3.2
Structural accessory of central beam elevation controlled via handle, gearbox and gear wheels
(( √ )) Basic type of central beam elevation as uncontrolled manual axis, HAS AN ALTERNATIVE (3.1, 3.3)
(( Combination )) Selection of this item precludes the selecting of item (3.1, 3.3)
(( Option )) Using the handle is possible to set any angle of central beam in the range of 0 - 90 °
(( Condition )) Assembled and mounted directly at the production
3.3
Structural accessory of motorized central beam elevation as part of control system - controlled Axis T
(( √ )) Advanced type of central beam elevation as controlled Axis T, HAS AN ALTERNATIVE (3.1, 3.2)
(( Combination )) Selection of this item precludes the selecting of item (3.1, 3.2)
(( Option )) Elevation has completely motoric drive, settings in the control system in the range of 0 - 90 °
(( Condition )) Assembled and mounted directly at the production
4
Equipping the machine with its own servo drive for longitudinal movement of torch head as controlled Axis X
(( √ )) Item is optional to increase variability when setting torch position, NO ALTERNATIVE
(( Combination )) Can be use with SW functions for layered and linear welding or torch oscillation (14.1, 14.2)
(( Options )) If not selected the machine is equipped with manually movable support with own brake
(( Condition )) Assembled and mounted directly at the production
5.1
Welding arm with three joints of releasing with simple pneumatic stroke of torch from working position
(( √ )) Item is necessary for intended function of the machine, HAS AN ALTERNATIVE (5.2)
(( Combination )) This item have to be further fitted with items (6.1), or (6.2)
(( Options )) None
(( Condition )) Assembled and mounted directly at the production
5.1
Welding arm with three joints of releasing with controlled motoric stroke of torch in axis Z
(( √ )) Item is necessary for intended function of the machine, HAS AN ALTERNATIVE (5.2)
(( Combination )) This item have to be further fitted with items (6.1), or (6.2)
(( Options )) None
(( Condition )) Assembled and mounted directly at the production
6.1
Cross head with precise adjustment of +/-15mm in axes X and Z and rotation of torch holder with fixation per each 30°
(( √ )) Item is necessary for intended function of the machine, HAS AN ALTERNATIVE
(( Combination )) This item have to be further fitted with item (ARM 2 TILT TORCH HOLDER)
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tools
6.2
Cross head with precise adjustment of +/-15mm in axes X and Z, rotation of torch holder with fixation per each 30° and side turning possibility +/- 90°
(( √ )) Item is necessary for intended function of the machine, HAS AN ALTERNATIVE
(( Combination )) This item have to be further fitted with item (ARM 2 TILT TORCH HOLDER)
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tools
6.3
Holder for MIG or TIG torch with tilting function at five fixed angles per each 15°
(( √ )) Item is necessary for intended function of the machine, NO ALTERNATIVE
(( Combination )) ARM 2 SLIDEMICRO is mounted on this part in the case of cold wire feeder is installed
(( Options )) Select a diameter of the torch, standard is 34mm. It have to always be a straight torch
(( Condition )) Can be installed in a simple operation without use of special tools
6.4
Holder for TIG torch with electromagnetic sensor for height tracking of the torch above the weldment
(( √ )) Can be used only in combination with numeric stroke of torch in Z axis, HAS AN ALTERNATIVE
(( Combination )) ARM 2 SLIDEMICRO is mounted on this part in the case of cold wire feeder is installed
(( Options )) Select a diameter of the torch, standard is 34mm. It have to always be a straight torch
(( Condition )) Assembled and mounted directly at the production
6.5
Holder for TIG torch with electromagnetic sensor for height tracking of the torch above the weldment
(( √ )) Can be used only in combination with numeric stroke of torch in Z axis, HAS AN ALTERNATIVE
(( Combination )) ARM 2 SLIDEMICRO is mounted on this part in the case of cold wire feeder is installed
(( Options )) Select a diameter of the torch, standard is 34mm. It have to always be a straight torch
(( Condition )) Assembled and mounted directly at the production
7.1
Feeder of cold wire 1,2 and 1,6 mm for TIG welding or PLASMA WELD
(( √ )) This item extends the functionality of the machine with effect to welding technology, NO ALTERNATIVE
(( Combination )) ARM 2 SLIDEMICRO have to be selected for proper function
(( Options )) If mounted on machines without a platform, it is advisable to select the feeder carrier
(( Condition )) Assembled and mounted directly at the production
7.2
Movable carrier for the Feeder CW 03, height 880 mm, platform tilt +/- 15 °
(( √ )) This item simplifies the adjusting of the CW 03 feeder, NO ALTERNATIVE
(( Combination )) With cold wire feeder CW 03
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tool
7.3
Cold wire feeding end element with the possibility of precise adjustment +/-5mm with cooled girder
(( √ )) Precisely made set feeds cold wire directly into the weld, NO ALTERNATIVE
(( Combination )) Mounted on the ARM 2 TILT TORCH HOLDER
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tool
8.1
SET for solenoid control of forming gas - one way
(( √ )) Auxiliary element that improves the operation by switching the forming gas flow, NO ALTERNATIVE
(( Combination )) None
(( Options )) None
(( Condition )) Assembled and mounted directly at the production
8.2
Separate float flow meter with precise needle valve. Mounting on the surface through hole
(( √ )) Auxiliary equipment that improves the machine funcionality, bringing gas savings, NO ALTERNATIVE
(( Combination )) Mounted on the machine or can be mounted on a free-standing carrier, height 950mm
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tools
9.1
Digital remote control with backlit display with the possibility of configuration of button functionality
(( √ )) Improves machine usability and facilitates direct welding control, NO ALTERNATIVE
(( Combination )) It is advisable to add a Holder for Mighty Controller
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tools
9.2
Holder for remote control Mighty Controller freely mountable on any surface or the machine
(( √ )) Reduces the risk of damage to the Mighty Controller, NO ALTERNATIVE
(( Combination )) Used in conjunction with Mighty Controller
(( Options )) None
(( Condition )) Can be installed in a simple operation without use of special tool
10.1
Set of internal electronics and installation elements for connecting of another source to the machine
(( √ )) Extends functionality of machine with the parallel welding with additional source, NO ALTERNATIVE
(( Combination )) Can be used with any kind of welding source on the analog START/STOP principle
(( Options )) Up to four simultaneous sources can be connected on request
(( Condition )) Assembled and mounted directly at the production
10.2
Set of internal electronics and installation elements for digital connection of welding source
(( √ )) Allows full control of welding source, including program switching, NO ALTERNATIVE
(( Combination )) Can be used only with HST CREATIVE and CEBORA, limitedly LORCH (on request)
(( Options )) Two independent welding sources can be connected
(( Condition )) Assembled and mounted directly at the production
11.1
Protective shield against the glare equipped with welding glass and pneumatically controlled tilting
(( √ )) Manually movable longitudinally along Axis X, equipped with brake, HAS AN ALTERNATIVE (12.2)
(( Combination )) None
(( Option )) None
(( Condition )) Assembled and mounted directly at the production
11.2
Protective shield against the glare equipped with welding glass and manually controlled tilting
(( √ )) Manually movable longitudinally along Axis X, equipped with brake, HAS AN ALTERNATIVE (12.1)
(( Combination )) None
(( Option )) None
(( Condition )) Assembled and mounted directly at the production
12
Separate ground cable on both sides terminated with a standard connection of 13mm
(( √ )) Copper cable closing the electric arc between the welding source and the machine, NO ALTERNATIVE
(( Combination )) None
(( Options )) Other cable lengths can be ordered on request
(( Condition )) Can be installed in a simple operation without use of special tools
13.1
Software extending functions of the machine with londitudinal welding and pendel function in rotary mode
(( √ )) Item is optional to increase the software functionality of machine, NO ALTERNATIVE
(( Combination )) Can be used only with drive of torch head longitudinal movement - controlled axis X (4.1)
(( Options )) None
(( Condition )) Installed directly at the production
13.2
Software extending functions of the machine with layered screw
(( √ )) Item is optional to increase the software functionality of machine, NO ALTERNATIVE
(( Combination )) Can be used only with drive of torch head longitudinal movement - controlled axis X (4)
(( Options )) None
(( Condition )) Installed directly at the production
14
Special set of weldment preheating containing complete technology, construction elements and SW equipment
(( √ )) Item is intended for preheating the material before welding on set temperature, NO ALTERNATIVE
(( Combination )) None
(( Options )) Preheating torch can be selected for any gaseous fuel
(( Condition )) Construction change which affects the design of the machine in an unchanging way
Accessories
0.A
Three-jaw universal chuck with gears adjusted for welding, hole 108mm, weight 42.5kg
(( √ )) Chuck can be mounted on spindle flanges without transition elements, HAS AN ALTERNATIVE
(( Combination )) The chuck can be fitted with extended segments (custom made solution)
(( Options )) Other chucks can be choosed, but these have to be mounted using transition elements
(( Condition )) Can be installed in a simple operation without use of special tools
0.B
Three-jaw universal chuck with gears adjusted for welding, hole 28mm, weight 4kg
(( √ )) Chuck can be mounted on spindle flanges without transition elements, HAS AN ALTERNATIVE
(( Combination )) The chuck can be fitted with extended segments (custom made solution)
(( Options )) Other chucks can be choose, but these have to be mounted using transition elements
(( Condition )) Can be installed in a simple operation without use of special tools
 Welding automat EWR 1050.108 |
 Welding automat EWR 1050.108 |
 Welding automat EWR 1050.108 |
 Welding automat EWR 1050.108 |
|||
 Welding automat EWR 1050.108 |
 Welding automat EWR 1050.108 |
 Welding automat EWR 1050.108 |
 Welding automat EWR 1050.108 |
|||
 Welding automat EWR 1050.108 |
 Welding automat EWR 1050.108 |
 Welding automat EWR 1050.108 |
